DPM-C530 Power Meter
6150 INR/Unit
Product Details:
- Product Type DPM-C530 Power Meter
- Usage High-precision Power Quality and Electricity Parameter Measurement
- Color Black
- Power Supply 35~690V AC (L-L)
- Power Consumption 3.7 Watt (W)
- Click to View more
X
DPM-C530 Power Meter Price And Quantity
- 1 Unit
- 6150 INR/Unit
DPM-C530 Power Meter Product Specifications
- 35~690V AC (L-L)
- High-precision Power Quality and Electricity Parameter Measurement
- DPM-C530 Power Meter
- Black
- 3.7 Watt (W)
DPM-C530 Power Meter Trade Information
- Cash Advance (CA)
- 1000 Unit Per Day
- 1 Days
- All India
Product Description
DPM-C530 Power Meter is extensively used in commercial areas for measuring current, voltage and frequency in an effective manner. With the help of avant-garde tools and techniques, the offered meter is manufactured using quality approved components by our ingenious professionals. In addition, it is highly durable, user friendly, compact in size and provides accurate measurement. Furthermore, our customers can avail this DPM-C530 Power Meter from us in different specifications at very nominal rates.
Specification
|
Alarm Parameter Selections |
29 types of Over/Under limit alarm |
|
Altitude |
Below 2000m |
|
Communication Interface |
RS-485 Interface, Modbus-RTU, Modbus-ASCII, Baud rate: 9600/19200/38400bps |
|
Dimension (W*H*D) |
96*96*95.4mm |
|
Frequency |
45 70Hz |
|
Humidity Rating |
95% RH |
|
IP Degree of Protection |
IP52(Front panel), IP20(Power meter) |
|
Operating Current |
1A/5A |
|
Operating Line Voltage |
35 690V AC (L-L) |
|
Operating Phase Voltage |
20 400V AC(L-N) |
|
Operating Range |
80 265VAC (Max. power consumption 3.7W) 100 300VDC |
|
Operating Temperature |
-20 degree C +70 degree C |
|
Storage Temerature |
-30 degree C +80 degree C |
|
Model Name/Number |
DPM-C530 |
|
Brand |
Delta |
