DOP-110WS Touch Panel Advanced HMI
28500 INR/Unit
Product Details:
- Weight 1.1 Kilograms (kg)
- Size 512 MB RAM ; 256 MB ROM
- Product Type DOP-110WS Touch Panel Advanced HMI
- Color Black
- Condition New
- Dimension (L*W*H) 270 x 180.9 x 47.25 Millimeter (mm)
- Voltage 24 DC Volt (v)
- Click to View more
X
DOP-110WS Touch Panel Advanced HMI Price And Quantity
- 1 Unit
- 28500 INR/Unit
DOP-110WS Touch Panel Advanced HMI Product Specifications
- New
- Black
- DOP-110WS Touch Panel Advanced HMI
- 512 MB RAM ; 256 MB ROM
- 1.1 Kilograms (kg)
- 24 DC Volt (v)
- 11 Watt (W)
- 270 x 180.9 x 47.25 Millimeter (mm)
- 3 Years
DOP-110WS Touch Panel Advanced HMI Trade Information
- Cash Advance (CA)
- 50 Unit Per Day
- 1 Days
- All India
Product Description
Graphical display based DOP-110WS Touch Panel Advanced HMI allows users to select various controlling options to receive their input in order to operate accordingly. Human machine interface makes any system user friendly and highly responsive. Available in 512 MB RAM and 256 MB ROM based specifications, this 1.1 kg touch panel is powered by 3v lithium battery that has 3 years or above life span. This HMI supports natural cooling method when its temperature rises due to continuous operation. Offered DOP-110WS Touch Panel Advanced HMI has standard safety features that conform to CE/UL norms.
Specification
|
Backup Battery |
3V lithium battery CR2032 x 1 |
|
Backup Battery Life |
About 3 years or more at 25 deg C but subjects to the temperature and the conditions during usage. |
|
Buzzer |
Multi-Tone Frequency (2 K 4 K Hz)/80 dB |
|
Cooling Method |
Natural cooling |
|
Dimension for Installation (W) x (H) mm |
255 x 170 |
|
Dimension (W) x (H) x (D) mm |
270 x 180.9 x 47.25 |
|
Ethernet Interface |
10/100 Mbps Auto sensing (with built-in isolated power circuit |
|
Flash ROM |
256 Mbytes |
|
Operating Environment |
10% 90% RH [0 40 C],10% 55% RH [41 50 C]; Pollution degree: 2 |
|
Operation Temperature |
0 deg C 50 deg C |
|
Operation Voltage (Note2) |
+24 V DC (-15% +15%) (with built-in isolated power supply unit) Supplied by Class 2 or SELV circui |
|
Perpetual Calendar |
Built-in |
|
Power Consumption |
11W (Max) (Note 3) |
|
Safety Approval |
CE / UL (Please use shielding Ethernet cable and the magnetic ring with filter of 300 ohm/100 MHz) |
|
Shock Resistance |
Conforms to IEC60068-2-27: 11 ms,15 G Peak,X,Y,Z direction for 6 times |
|
Storage Temperature |
-20 deg C +60 deg C |
|
USB |
1 USB Slave Ver 2.0 1 USB Host Ver 2.0 |
|
Vibration Resistance |
Conforms to IEC61131-2; Continuous: 5 Hz 8.3 Hz 3.5 mm,8.3 Hz 150 Hz 1 G |
|
Voltage Endurance |
500 V AC for 1 minute (between charging (DC24V terminal) and FG terminals) |
|
Waterproof Level of Panel Display |
IP65(Not be evaluated by UL)/NEMA4/ Type 4X indoor use only |
|
Brand |
Delta |
|
RAM |
512 Mbytes |
|
Weight |
Approx. 1.1 Kgs |
|
Model Name/Number |
DOP-110WS |
|
Touch Screen Type |
4-wire resistive touch screen Greater than 10,000,000 operated |
